| Číslo dielu | TX23D85VM0BAA |
| Značka | KOE |
| Veľkosť | 9.0 |
| Aplikácia | IA |
| Rozhodnutie | 1280×768 |
| Zloženie | LCM |
| Jas | |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | HITACHI |
| panelový model | TX23D85VM0BAA |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 9.0 inch |
| rozhodnutie | 1280(RGB)×768 , WXGA |
| režim zobrazenia | IPS, Normally Black, Transmissive |
| aktívna oblasť | 193.92×116.352 mm |
| povrch | |
| jas | |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR＞10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (1 ch, 8-bit) |
| aplikácie | IA |
