| Číslo dielu | NL10276AC28-05R |
| Značka | NLT |
| Veľkosť | 14.1 |
| Aplikácia | DMPC |
| Rozhodnutie | 1024×768 |
| Zloženie | LCM |
| Jas | 220 |
| CR | 150:1 |
| Farby | 262K |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | NEC |
| panelový model | NL10276AC28-05R |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 14.1 inch |
| rozhodnutie | 1024(RGB)×768 , XGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 285.696×214.272 mm |
| obrys | 330×255×20.5 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 220 cd/m² (Typ.) |
| kontrastný pomer | 150:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193140% |
| Doba odozvy | 11/40 (Typ.)(Tr/Td) |
| pozorovací uhol | 50/50/20/35 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 2 pcsCCFLEmbedded (Inverter) |
| signálové rozhranie | LVDS (1 ch, 6-bit), 20 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
