| Číslo dielu | NL10276BC30-34D |
| Značka | NLT |
| Veľkosť | 15.0 |
| Aplikácia | IA |
| Rozhodnutie | 1024×768 |
| Zloženie | LCM |
| Jas | 500 |
| CR | 600:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | NEC |
| panelový model | NL10276BC30-34D |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 15.0 inch |
| rozhodnutie | 1024(RGB)×768 , XGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 304.128×228.096 mm |
| obrys | 326.5×253.5×12 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 500 cd/m² (Typ.) |
| kontrastný pomer | 600:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC), CIE193150% |
| Doba odozvy | 3/15 (Typ.)(Tr/Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 6 stringsWLEDOptional |
| signálové rozhranie | LVDS (1 ch, 8-bit), 20 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | IA |
| NL10276AC24-05 | NLT | 12.1 | 1024×768 |
| NL10276AC28-05R | NLT | 14.1 | 1024×768 |
| NL10276BC16-01 | NLT | 8.4 | 1024×768 |
| NL10276BC20-04 | NLT | 10.4 | 1024×768 |
| NL10276BC20-08 | NLT | 10.4 | 1024×768 |
| NL10276BC20-18F | NLT | 10.4 | 1024×768 |
| NL10276BC20-37 | NLT | 10.4 | 1024×768 |
| NL10276BC30-17 | NLT | 15.0 | 1024×768 |
| NL10276BC30-18C | NLT | 15.0 | 1024×768 |
| NL10276BC30-38B | NLT | 15.0 | 1024×768 |
| AM-640480G2TNQW-00H-F | AMPIRE | 5.7 | 640×480 |
| G104SN03 V0 | AUO | 10.4 | 800×600 |
| KHB065HV1BD-M10 | Kyocera | 6.5 | 640×240 |
| LQ070Y3DG3A | SHARP | 7.0 | 800×480 |
| M101GWN9 R2 | IVO | 10.1 | 1024×600 |
| MAA121DSK26 | Mitsubishi | 12.1 | 800×600 |
| NL6448BC33-64D | NLT | 10.4 | 640×480 |
| NL8048BC19-02C | NLT | 7.0 | 800×480 |
| NL8060BC26-17 | NLT | 10.4 | 800×600 |
| UMSH-8377MD-8T | Other | 5.7 | 640×480 |
