| Číslo dielu | M240J1-L03 |
| Značka | Innolux |
| Veľkosť | 24.0 |
| Aplikácia | DMPC |
| Rozhodnutie | 1920×1200 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | CMO |
| panelový model | M240J1-L03 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 24.0 inch |
| rozhodnutie | 1920(RGB)×1200 , WUXGA |
| režim zobrazenia | Super MVA, Normally Black, Transmissive |
| aktívna oblasť | 518.4×324 mm |
| obrys | 546.4×352 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 13/7 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| pozorovací uhol | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 6 pcsCCFLEmbedded (Inverter) |
| signálové rozhranie | LVDS (1 ch, 8-bit), 30 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
