| Číslo dielu | M201P1-L03 |
| Značka | Innolux |
| Veľkosť | 20.1 |
| Aplikácia | DMPC |
| Rozhodnutie | 1400×1050 |
| Zloženie | LCM |
| Jas | 300 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | CMO |
| panelový model | M201P1-L03 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 20.1 inch |
| rozhodnutie | 1400(RGB)×1050 , SXGA+ |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 408.24×306.18 mm |
| obrys | 432×331.5 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC) |
| Doba odozvy | 1.3/3.7 (Typ.)(Tr/Td) |
| pozorovací uhol | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (2 ch, 8-bit), 30 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
