| Číslo dielu | M201UN04 V0 |
| Značka | AUO |
| Veľkosť | 20.1 |
| Aplikácia | DMPC |
| Rozhodnutie | 1600×1200 |
| Zloženie | LCM |
| Jas | 300 |
| CR | 800:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | AUO |
| panelový model | M201UN04 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 20.1 inch |
| rozhodnutie | 1600(RGB)×1200 , UXGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 408×306 mm |
| obrys | 432×331.5×25.5 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Doba odozvy | 4.5/1.5 (Typ.)(Tr/Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (2 ch, 8-bit), 30 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
