| Číslo dielu | LTL070AL03 |
| Značka | Samsung |
| Veľkosť | 7.0 |
| Aplikácia | PAD |
| Rozhodnutie | 800×1280 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 900:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | SAMSUNG |
| panelový model | LTL070AL03 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 800(RGB)×1280 , WXGA |
| režim zobrazenia | PLS, Normally Black, Transmissive |
| aktívna oblasť | 94.2×150.72 mm |
| obrys | 99.7×160.93×3.6 mm |
| povrch | Hard coating (2H), Antireflection |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 900:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193150% |
| Doba odozvy | 25 (Typ.)(Tr+Td) |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 4 stringsWLEDWithout Driver |
| signálové rozhranie | MIPI (4 data lanes), 34 pins |
| vstupné napätie | 1.8/3.3V (Typ.)(VDD/VDD3) |
| aplikácie | PAD |
