| Číslo dielu | LQ070Y5DG36 |
| Značka | SHARP |
| Veľkosť | 7.0 |
| Aplikácia | CNS |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 485 |
| CR | 150:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | SHARP |
| panelový model | LQ070Y5DG36 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 800×480(RGB) , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 156.4×82.08 mm |
| obrys | 165.2×92.4×11.06 mm |
| povrch | |
| jas | 485 cd/m² (Typ.) |
| kontrastný pomer | 150:1 (Min.) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 20/30 (Typ.)(Tr/Td) |
| pozorovací uhol | 65/65/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 6S4PWLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | CNS |
