| Číslo dielu | BF097XN |
| Značka | Innolux |
| Veľkosť | 9.7 |
| Aplikácia | PAD |
| Rozhodnutie | 1024×768 |
| Zloženie | LCM |
| Jas | 420 |
| CR | 900:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | CHIMEI INNOLUX |
| panelový model | BF097XN |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 9.7 inch |
| rozhodnutie | 1024(RGB)×768 , XGA |
| režim zobrazenia | IPS, Normally Black, Transmissive |
| aktívna oblasť | 196.608×147.456 mm |
| obrys | 210×164.25×5.25 mm |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 420 cd/m² (Typ.) |
| kontrastný pomer | 900:1 (Typ.) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 20 (Typ.)(G to G); 20 (Typ.)(Tr+Td) |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 6S6PWLEDWithout Driver |
| signálové rozhranie | LVDS (1 ch, 6-bit), 30 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
