| Číslo dielu | LP125WH2-SLB3 |
| Značka | LG Display |
| Veľkosť | 12.5 |
| Aplikácia | PAD |
| Rozhodnutie | 1366×768 |
| Zloženie | LCM |
| Jas | 300 |
| CR | 500:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | LG Display |
| panelový model | LP125WH2-SLB3 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 12.5 inch |
| rozhodnutie | 1366(RGB)×768 , WXGA |
| režim zobrazenia | IPS, Normally Black, Transmissive |
| aktívna oblasť | 275.59×154.94 mm |
| obrys | 300.4×180.9×3.7 mm |
| povrch | Antiglare |
| jas | 300 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Min.) |
| zobraziť farby | 262K (6-bit), CIE193150% |
| Doba odozvy | 35 (Typ.)(Tr+Td) |
| pozorovací uhol | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (1 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
| LP125WF1-SPD1 | LG Display | 12.5 | 1920×1080 |
| LP125WF2-SPB1 | LG Display | 12.5 | 1920×1080 |
| LP125WH2-SLB1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLB2 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLB3 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLT1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SPR1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SPT1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLD1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLE1 | LG Display | 12.5 | 1366×768 |
| B080XAN01.0 | AUO | 7.9 | 768×1024 |
| EJ101IA-01C | Innolux | 10.1 | 1280×800 |
| HV101HD1-1E0 | HYDIS | 10.1 | 1366×768 |
| HV121WX5-120 | HYDIS | 12.1 | 1280×800 |
| LD101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| LP079X01-SMA7 | LG Display | 7.9 | 768×1024 |
| LPM089A001A | JDI | 8.9 | 2560×1600 |
| N101ICG-L21 Rev.C1 | Innolux | 10.1 | 1280×800 |
| VVX07H005A10 | Panasonic | 7.0 | 800×1280 |
| ZE090NA-01B | Innolux | 9.0 | 1280×800 |
