| Číslo dielu | LP101WX2-SLA1 |
| Značka | LG Display |
| Veľkosť | 10.1 |
| Aplikácia | PAD |
| Rozhodnutie | 1280×800 |
| Zloženie | Assembly |
| Jas | 360 |
| CR | 500:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | LG Display |
| panelový model | LP101WX2-SLA1 |
| typ panelu | a-Si TFT-LCD , Assembly |
| veľkosť panelu | 10.1 inch |
| rozhodnutie | 1280(RGB)×800 , WXGA |
| aktívna oblasť | 216.96×135.6 mm |
| obrys | 257.2×175.4×5.9 mm |
| povrch | Anti Fingerprint |
| jas | 360 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Min.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC) |
| pozorovací uhol | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| signálové rozhranie | LVDS (1 ch, 8-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
| LP101WH1-TLA1 | LG Display | 10.1 | 1366×768 |
| LP101WH1-TLB5 | LG Display | 10.1 | 1366×768 |
| LP101WH2-TLA2 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLAB | LG Display | 10.1 | 1366×768 |
| LP101WS1-TLB2 | LG Display | 10.1 | 1024×576 |
| LP101WSA-TLA1 | LG Display | 10.1 | 1024×600 |
| LP101WSA-TLB1 | LG Display | 10.1 | 1024×600 |
| LP101WX1-SLB1 | LG Display | 10.1 | 1280×800 |
| LP101WX1-SLP2 | LG Display | 10.1 | 1280×800 |
| LP101WX2-SLA1 | LG Display | 10.1 | 1280×800 |
| B116XAN03.1 HW1A | AUO | 11.6 | 1366×768 |
| CLAA080WQ02 XN | CPT | 8.0 | 800×1280 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| HV101HD1-1E2 | HYDIS | 10.1 | 1366×768 |
| LD080UX1-SMA2 | LG Display | 8.0 | 1200×1600 |
| LP097QX1-SPC1 | LG Display | 9.7 | 2048×1536 |
| LSL080AL02-002 | Samsung | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.A1 | Innolux | 8.0 | 800×1280 |
| TV097X0M-NS0 | BOE | 9.7 | 768×1024 |
| VVX10F008B00 | Panasonic | 10.1 | 1920×1200 |
