| Číslo dielu | B116XAN03.1 HW1A |
| Značka | AUO |
| Veľkosť | 11.6 |
| Aplikácia | PAD |
| Rozhodnutie | 1366×768 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 800:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | AUO |
| panelový model | B116XAN03.1 HW1A |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 11.6 inch |
| rozhodnutie | 1366(RGB)×768 , WXGA |
| režim zobrazenia | AHVA, Normally Black, Transmissive |
| aktívna oblasť | 256.125×144 mm |
| obrys | 270.37×159.79×4.8 mm |
| povrch | Antiglare |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193150% |
| Doba odozvy | 25 (Typ.)(Tr+Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 10S3PWLEDEmbedded (LED Driver) |
| signálové rozhranie | MIPI (4 data lanes), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
