| Číslo dielu | LQ035NC211 |
| Značka | Innolux |
| Veľkosť | 3.5 |
| Aplikácia | DSC |
| Rozhodnutie | 320×240 |
| Zloženie | LCM |
| Jas | 200 |
| CR | 400:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | Parallel/Serial |
| značka panelu | ChiHsin |
| panelový model | LQ035NC211 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 3.5 inch |
| rozhodnutie | 320(RGB)×240 , QVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 70.08×52.56 mm |
| obrys | 76.9×63.9×4.56 mm |
| povrch | Antiglare (Haze 20%) |
| jas | 200 cd/m² (Typ.) |
| kontrastný pomer | 400:1 (Typ.) |
| zobraziť farby | 16.7M , CIE193160% |
| Doba odozvy | 10/15 (Typ.)(Tr/Td) |
| pozorovací uhol | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 6S1PWLEDWithout Driver |
| signálové rozhranie | Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins |
| vstupné napätie | 3.3V (Typ.)(VCC) |
| aplikácie | DSC |
| LQ035NC211 | Innolux | 3.5 | 320×240 |
| LQ035Q1DG01 | SHARP | 3.5 | 320×240 |
| LQ035Q1DG02 | SHARP | 3.5 | 320×240 |
| LQ035Q1DH01 | SHARP | 3.5 | 320×240 |
| LQ035Q7DB03F | SHARP | 3.5 | 240×320 |
| LQ035Q7DB04 | SHARP | 3.5 | 240×320 |
| LQ035Q7DB05 | SHARP | 3.5 | 240×320 |
| LQ035Q7DH02 | SHARP | 3.5 | 240×320 |
| LQ035Q7DH05 | SHARP | 3.5 | 240×320 |
| LQ035Q7DH06 | SHARP | 3.5 | 240×320 |
| A027DN01 VQ | AUO | 2.7 | 320×240 |
| A027DN03 V3 | AUO | 2.7 | 320×240 |
| A027DN04 V4 | AUO | 2.7 | 320×240 |
| L3F04X-80300C | Epson | 0.48 | 1024×768 |
| LQ035JC211 | Innolux | 3.5 | 320×240 |
| LTV350QV-F04 | Samsung | 3.5 | 320×240 |
| PA025XSC | E Ink | 2.5 | 480×234 |
| PD035OX1 | E Ink | 3.5 | 320×234 |
| TD024THEB5 | TPO | 2.4 | 480×240 |
| TD025THEG1 | TPO | 2.5 | 320×240 |
