| Číslo dielu | LB084S02-TD01 |
| Značka | LG Display |
| Veľkosť | 8.4 |
| Aplikácia | DPF |
| Rozhodnutie | 800×600 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 500:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | LG.Philips LCD |
| panelový model | LB084S02-TD01 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 8.4 inch |
| rozhodnutie | 800(RGB)×600 , SVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 170.4×127.8 mm |
| obrys | 189.8×149.4 mm |
| povrch | Antiglare |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193146% |
| Doba odozvy | 10/15 (Typ.)(Tr/Td) |
| pozorovací uhol | 65/65/45/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 3S9PWLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 6-bit), 60 pins |
| vstupné napätie | 3.3/10/19.5/-4.5/4.12V (Typ.)(VCC/AVDD/VGH/VGL/VCOM) |
| aplikácie | DPF |
| AA084SD01 | Mitsubishi | 8.4 | 800×600 |
| G084SN05 V7 | AUO | 8.4 | 800×600 |
| G084SN05 V8 | AUO | 8.4 | 800×600 |
| G084SN05 V9 | AUO | 8.4 | 800×600 |
| LB084S01-TL01 | LG Display | 8.4 | 800×600 |
| LB084S02-TD01 | LG Display | 8.4 | 800×600 |
| LQ9D023 | SHARP | 8.4 | 640×480 |
| LTM08C351 | TOSHIBA | 8.4 | 800×600 |
| MAA084DXA03 | Mitsubishi | 8.4 | 1024×768 |
| NL10276BC16-01 | NLT | 8.4 | 1024×768 |
| A101VW01 V3 | AUO | 10.1 | 800×480 |
| AT056TN53 V.1 | Innolux | 5.6 | 640×480 |
| AT070TN90 | Innolux | 7.0 | 800×480 |
| AT080TN52 V.1 | Innolux | 8.0 | 800×600 |
| HSD090IDW1-A00 | HannStar | 9.0 | 800×480 |
| HSD100IFW1-A04 | HannStar | 10.1 | 1024×600 |
| LSA40AT9001 | Innolux | 10.4 | 800×600 |
| LTA120W1-T02 | Samsung | 12.0 | 800×480 |
| PA079DS1T2 | E Ink | 7.9 | 480×234 |
| PM070WM3 | E Ink | 7.0 | 800×480 |
