| Číslo dielu | A101VW01 V3 |
| Značka | AUO |
| Veľkosť | 10.1 |
| Aplikácia | DPF |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 300 |
| CR | 500:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | AUO |
| panelový model | A101VW01 V3 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 10.1 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 219.6×131.76 mm |
| obrys | 235×145.9 mm |
| povrch | Antiglare |
| jas | 300 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193148% |
| Doba odozvy | 12/18 (Typ.)(Tr/Td) |
| pozorovací uhol | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 3S11PWLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 6-bit), 60 pins |
| vstupné napätie | 3.3/8.8/15/-7.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikácie | DPF |
