| Číslo dielu | AT056TN53 V.1 |
| Značka | Innolux |
| Veľkosť | 5.6 |
| Aplikácia | DPF |
| Rozhodnutie | 640×480 |
| Zloženie | LCM |
| Jas | 350 |
| CR | 500:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | INNOLUX |
| panelový model | AT056TN53 V.1 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 5.6 inch |
| rozhodnutie | 640(RGB)×480 , VGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 112.896×84.672 mm |
| obrys | 126.5×100 mm |
| povrch | Antiglare |
| jas | 350 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193150% |
| Doba odozvy | 10/15 (Typ.)(Tr/Td) |
| pozorovací uhol | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | Parallel RGB (1 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.)(VCC) |
| rohs: | |
| aplikácie | DPF |
| AT056TN03 | Innolux | 5.6 | 320×234 |
| AT056TN04 V.6 | Innolux | 5.6 | 320×234 |
| AT056TN52 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.2 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.3 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.4 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.5 | Innolux | 5.6 | 640×480 |
| AT056TN53 V.1 | Innolux | 5.6 | 640×480 |
| LTD056ET0T | TOSHIBA | 5.6 | 1024×600 |
| TM056KDH01 | Tianma | 5.6 | 320×234 |
| A080SN01 V0 | AUO | 8.0 | 800×600 |
| A085FW01 V5 | AUO | 8.5 | 480×234 |
| HSD070ISN1-D00 | HannStar | 7.0 | 800×600 |
| HSD090ICW1-A00 | HannStar | 9.0 | 640×234 |
| HSD101PFW1-A01 | HannStar | 10.1 | 1024×576 |
| HSD101PFW2-B01 | HannStar | 10.1 | 1024×600 |
| HSD101PFW4-B01 | HannStar | 10.1 | 1024×600 |
| LW850AT9301 | Innolux | 8.5 | 800×480 |
| PA079DS4 | E Ink | 7.9 | 480×234 |
| TM060RDH03 | Tianma | 6.0 | 800×480 |
