| Číslo dielu | HSD101PWW1-H00 |
| Značka | HannStar |
| Veľkosť | 10.1 |
| Aplikácia | PAD |
| Rozhodnutie | 1280×800 |
| Zloženie | LCM |
| Jas | 300 |
| CR | 800:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | HannStar |
| panelový model | HSD101PWW1-H00 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 10.1 inch |
| rozhodnutie | 1280(RGB)×800 , WXGA |
| režim zobrazenia | HS-IPS, Normally Black, Transmissive |
| aktívna oblasť | 216.96×135.6 mm |
| obrys | 229.46×149.2×5.2 mm |
| povrch | Hard coating |
| jas | 300 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193145% |
| Doba odozvy | 25 (Typ.)(Tr+Td) |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (1 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
| HSD101PFW1-A01 | HannStar | 10.1 | 1024×576 |
| HSD101PFW2-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW2-B00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW3-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PUW1-A00 | HannStar | 10.1 | 1920×1200 |
| HSD101PWW1-A00 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-B00-C11 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-F00 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-F01 | HannStar | 10.1 | 1280×800 |
| HSD101PWW2-A01 | HannStar | 10.1 | 1280×800 |
| A070PAN01.0 | AUO | 7.0 | 900×1440 |
| B101UAN01.7 HW0A | AUO | 10.1 | 1920×1200 |
| CLAA080WQ05 | CPT | 8.0 | 800×1280 |
| HJ101IA-01I | Innolux | 10.1 | 1280×800 |
| LP101WH4-SLA3 | LG Display | 10.1 | 1366×768 |
| LTL070NL01-801 | Samsung | 7.0 | 1024×600 |
| LTL106HL01-001 | Samsung | 10.6 | 1920×1080 |
| LTN121AP05-302 | Samsung | 12.1 | 1280×800 |
| N070ICE-G02 Rev.C3 | Innolux | 7.0 | 800×1280 |
| N101ICG-L21 Rev.C2 | Innolux | 10.1 | 1280×800 |
