| Číslo dielu | A070PAN01.0 |
| Značka | AUO |
| Veľkosť | 7.0 |
| Aplikácia | PAD |
| Rozhodnutie | 900×1440 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 900:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | AUO |
| panelový model | A070PAN01.0 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 900(RGB)×1440 , WXGA+ |
| režim zobrazenia | AHVA, Normally Black, Transmissive |
| aktívna oblasť | 94.23×150.77 mm |
| obrys | 104.53×163.64×2.3 mm |
| povrch | Hard coating |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 900:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193150% |
| Doba odozvy | 18/12 (Typ.)(Tr/Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 5S4PWLEDWithout Driver |
| signálové rozhranie | MIPI (4 data lanes), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
