| Číslo dielu | HQ097QX1-IPS |
| Značka | Other |
| Veľkosť | 9.7 |
| Aplikácia | PAD |
| Rozhodnutie | 2048×1536 |
| Zloženie | LCM |
| Jas | 420 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | eDP |
| značka panelu | No Brand |
| panelový model | HQ097QX1-IPS 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 9.7 inch |
| rozhodnutie | 2048(RGB)×1536 , QXGA |
| režim zobrazenia | PLS, Normally Black, Transmissive |
| aktívna oblasť | 196.608×147.456 mm |
| obrys | 208.88×167.12 mm |
| povrch | Glare (Haze 0%), Hard coating (2H), Reflection 1.45% (Max.) |
| jas | 420 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 16 (Typ.)(Tr+Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhranie | eDP (4 Lanes), 51 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
