| Číslo dielu | G104X1-L02 |
| Značka | Innolux |
| Veľkosť | 10.4 |
| Aplikácia | GM |
| Rozhodnutie | 1024×768 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 1200:1 |
| Farby | 16.2M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | CMO |
| panelový model | G104X1-L02 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 10.4 inch |
| rozhodnutie | 1024(RGB)×768 , XGA |
| režim zobrazenia | Super MVA, Normally Black, Transmissive |
| aktívna oblasť | 210.4×157.8 mm |
| obrys | 225.5×176.3×10.67 mm |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 1200:1 (Typ.) |
| zobraziť farby | 16.2M (6-bit + FRC), CIE193157% |
| Doba odozvy | 14/11 (Typ.)(Tr/Td) |
| pozorovací uhol | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (1 ch, 8-bit), 30 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | GM |
| AA104VC01 | Mitsubishi | 10.4 | 640×480 |
| G104X1-L01 | Innolux | 10.4 | 1024×768 |
| G104X1-L02 | Innolux | 10.4 | 1024×768 |
| G104X1-L03 | Innolux | 10.4 | 1024×768 |
| G104X1-L04 | Innolux | 10.4 | 1024×768 |
| G104XGE-L05 | Innolux | 10.4 | 1024×768 |
| G104XVN01.0 | AUO | 10.4 | 1024×768 |
| LTA104S2-L01 | Samsung | 10.4 | 800×600 |
| LTM10C348F | TOSHIBA | 10.4 | 800×600 |
| NL6448BC33-20 | NLT | 10.4 | 640×480 |
| A084SN01 V1 | AUO | 8.4 | 800×600 |
| G190EG01 V1 | AUO | 19.0 | 1280×1024 |
| HV104X01-100 | HYDIS | 10.4 | 1024×768 |
| LQ104V1LG92 | SHARP | 10.4 | 640×480 |
| LQ150X1LW94 | SHARP | 15.0 | 1024×768 |
| LQ156T3LW02 | SHARP | 15.6 | 1366×768 |
| LQ170E1LG21 | SHARP | 17.0 | 1280×1024 |
| LTA159B870F | TOSHIBA | 15.9 | 1280×645 |
| LTA170D200F | TOSHIBA | 17.0 | 1280×1024 |
| TX39D01VM1BAA | KOE | 15.4 | 1280×768 |
