| Číslo dielu | G070Y3-T01 |
| Značka | Innolux |
| Veľkosť | 7.0 |
| Aplikácia | IA |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 600 |
| CR | 650:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | CMO |
| panelový model | G070Y3-T01 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 156×82.8 mm |
| obrys | 168×94×6.65 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 600 cd/m² (Typ.) |
| kontrastný pomer | 650:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193160% |
| Doba odozvy | 5/11 (Typ.)(Tr/Td) |
| pozorovací uhol | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 9S3PWLEDWithout Driver |
| signálové rozhranie | TTL (1 ch, 6-bit), 50 pins |
| vstupné napätie | 3.3/10.5/18/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikácie | IA |
