| Číslo dielu | BP101WX1-210 |
| Značka | BOE |
| Veľkosť | 10.1 |
| Aplikácia | PAD |
| Rozhodnutie | 1280×800 |
| Zloženie | LCM |
| Jas | 330 |
| CR | 600:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | BOE |
| panelový model | BP101WX1-210 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 10.1 inch |
| rozhodnutie | 1280(RGB)×800 , WXGA |
| režim zobrazenia | ADS, Normally Black, Transmissive |
| aktívna oblasť | 216.96×135.6 mm |
| obrys | 228.3×149.05×4.4 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 330 cd/m² (Typ.) |
| kontrastný pomer | 600:1 (Min.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC), CIE193150% |
| Doba odozvy | 25 (Typ.)(Tr+Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 6 stringsWLEDWithout Driver |
| signálové rozhranie | MIPI (4 data lanes), 39 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
| B101AW03 V1 | AUO | 10.1 | 1024×600 |
| BP101WX1-100 | BOE | 10.1 | 1280×800 |
| BP101WX1-200 | BOE | 10.1 | 1280×800 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| BP101WX1-210 | BOE | 10.1 | 1280×800 |
| BP101WX1-300 | BOE | 10.1 | 1280×800 |
| BP101WX1-400 | BOE | 10.1 | 1280×800 |
| G101ICE-L01 | Innolux | 10.1 | 1280×800 |
| LTN101AL03-801 | Samsung | 10.1 | 1280×800 |
| M101GWN9 R0 | IVO | 10.1 | 1024×600 |
| B079XAN01.0 | AUO | 7.9 | 768×1024 |
| B101UAN01.7 HW0A | AUO | 10.1 | 1920×1200 |
| B101UAN01.7 HW1A | AUO | 10.1 | 1920×1200 |
| B116XAN03.1 HW1A | AUO | 11.6 | 1366×768 |
| HSD101PWW1-B00 | HannStar | 10.1 | 1280×800 |
| LP094WX1-SLA2 | LG Display | 9.4 | 1280×800 |
| LQ101R1SX01A | SHARP | 10.1 | 2560×1600 |
| LTL089CL02-W02 | Samsung | 8.9 | 1920×1200 |
| TV101WXM-NP1 | BOE | 10.1 | 1280×800 |
| VVF07H119A90 | Panasonic | 7.0 | 800×1280 |
