| Číslo dielu | AM-800480LTMQW-00H-F |
| Značka | AMPIRE |
| Veľkosť | 5.0 |
| Aplikácia | IA |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 250:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | AMPIRE |
| panelový model | AM-800480LTMQW-00H-F |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 5.0 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 108×64.8 mm |
| obrys | 119×77.1×3.41 mm |
| povrch | Glare (Haze 0%) |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 250:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193152% |
| Doba odozvy | 15/35 (Typ.)(Tr/Td) |
| pozorovací uhol | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 3S6PWLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 8-bit), 45 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | IA |
