| Číslo dielu | RGS24128022YR000 |
| Značka | RiTdisplay |
| Veľkosť | 2.4 |
| Aplikácia | IA |
| Rozhodnutie | 128×22 |
| Zloženie | OLED |
| Jas | 100 |
| CR | 2000:1 |
| Farby | Mono(Yellow) |
| Podsvietenie | self |
| Rozhranie | CPU/SPI/I²C |
| značka panelu | RiTdisplay |
| panelový model | RGS24128022YR000 |
| typ panelu | PM-OLED , OLED |
| veľkosť panelu | 2.4 inch |
| rozhodnutie | 128×22 |
| aktívna oblasť | 58.85×11.85 mm |
| obrys | 63.3×20.8×2.25 mm |
| povrch | Antiglare |
| jas | 100 cd/m² (Typ.) |
| kontrastný pomer | 2000 : 1 (Min.) |
| zobraziť farby | Mono(Yellow) (1-bit) |
| pozorovací uhol | 80/80/80/80 (Min.)(L/R/U/D) |
| frekvencia | 105Hz |
| vodič ic | COG Built-in SSD1305 |
| signálové rozhranie | 8-bit 6800/8080 parallel, SPI, I²C, 24 pins |
| vstupné napätie | 12.0V (Typ.) |
| aplikácie | IA |
