| Číslo dielu | BTL507212-W746L |
| Značka | BOE |
| Veľkosť | 5.0 |
| Aplikácia | MPH |
| Rozhodnutie | 720×1280 |
| Zloženie | LCM |
| Jas | |
| CR | 700:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | BOE |
| panelový model | BTL507212-W746L |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 5.0 inch |
| rozhodnutie | 720(RGB)×1280 , WXGA |
| režim zobrazenia | ADS, Normally Black, Transmissive |
| aktívna oblasť | 62.1×110.4 mm |
| povrch | |
| jas | |
| kontrastný pomer | 700:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193170% |
| Doba odozvy | 35 (Typ.)(Tr+Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhranie | MIPI (4 data lanes), 27 pins |
| vstupné napätie | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| aplikácie | MPH |
