| Číslo dielu | AM-1024600KTMQW-01H |
| Značka | AMPIRE |
| Veľkosť | 7.0 |
| Aplikácia | IA |
| Rozhodnutie | 1024×600 |
| Zloženie | LCM |
| Jas | 1000 |
| CR | 700:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | AMPIRE |
| panelový model | AM-1024600KTMQW-01H |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 1024(RGB)×600 , WSVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 153.6×90 mm |
| obrys | 165.5×104.44×7.91 mm |
| povrch | Glare (Haze 0%), Hard coating |
| jas | 1000 cd/m² (Typ.) |
| kontrastný pomer | 700:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 10/15 (Typ.)(Tr/Td) |
| pozorovací uhol | 75/75/70/75 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 8S3PWLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (1 ch, 8-bit), 20 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | IA |
