| Číslo dielu | NL6448BC18-06F |
| Značka | NLT |
| Veľkosť | 5.7 |
| Aplikácia | IA |
| Rozhodnutie | 640×480 |
| Zloženie | LCM |
| Jas | 800 |
| CR | 850:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | NEC |
| panelový model | NL6448BC18-06F |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 5.7 inch |
| rozhodnutie | 640(RGB)×480 , VGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 116.16×87.12 mm |
| obrys | 135×104.6×11 mm |
| povrch | Clear, Hard coating (3H) |
| jas | 800 cd/m² (Typ.) |
| kontrastný pomer | 850:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193160% |
| Doba odozvy | 3/15 (Typ.)(Tr/Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 9S2P×2CNWLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | IA |
| NL6448BC18-06F | NLT | 5.7 | 640×480 |
| NL6448BC20-08 | NLT | 6.5 | 640×480 |
| NL6448BC20-18D | NLT | 6.5 | 640×480 |
| NL6448BC20-35D | NLT | 6.5 | 640×480 |
| NL6448BC26-01 | NLT | 8.4 | 640×480 |
| NL6448BC26-08D | NLT | 8.4 | 640×480 |
| NL6448BC26-09 | NLT | 8.4 | 640×480 |
| NL6448BC26-11 | NLT | 8.4 | 640×480 |
| NL6448BC33-59 | NLT | 10.4 | 640×480 |
| NL6448BC33-59D | NLT | 10.4 | 640×480 |
| G104V1-T03 | Innolux | 10.4 | 640×480 |
| G220SW01 V0 | AUO | 22.0 | 1680×1050 |
| LQ104S1LG31 | SHARP | 10.4 | 800×600 |
| LQ104V1DG21 | SHARP | 10.4 | 640×480 |
| LQ9D001 | SHARP | 8.4 | 640×480 |
| LTD121C33U | TOSHIBA | 12.1 | 800×600 |
| MD400F640PD5 | Panasonic | 9.8 | 640×400 |
| NL10276BC16-06D | NLT | 8.4 | 1024×768 |
| NL6448BC33-70D | NLT | 10.4 | 640×480 |
| SP14N002 | KOE | 5.1 | 240×128 |
