| Číslo dielu | G260J1-L05 |
| Značka | Innolux |
| Veľkosť | 25.5 |
| Aplikácia | IA |
| Rozhodnutie | 1920×1200 |
| Zloženie | LCM |
| Jas | 350 |
| CR | 1500:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | CHIMEI INNOLUX |
| panelový model | G260J1-L05 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 25.5 inch |
| rozhodnutie | 1920(RGB)×1200 , WUXGA |
| režim zobrazenia | Super MVA, Normally Black, Transmissive |
| aktívna oblasť | 550.08×343.8 mm |
| obrys | 582×375.6 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 350 cd/m² (Typ.) |
| kontrastný pomer | 1500:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193192% |
| Doba odozvy | 15/5 (Typ.)(Tr/Td) |
| pozorovací uhol | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 16 pcsCCFLEmbedded (Inverter) |
| signálové rozhranie | LVDS (2 ch, 8-bit), 30 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | IA |
