| Číslo dielu | A101AIE40L0 |
| Značka | Aptus |
| Veľkosť | 10.1 |
| Aplikácia | IA |
| Rozhodnutie | 1280×720 |
| Zloženie | LCM |
| Jas | 500 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | Aptus |
| panelový model | A101AIE40L0 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 10.1 inch |
| rozhodnutie | 1280(RGB)×720 , WXGA |
| režim zobrazenia | AHVA, Normally Black, Transmissive |
| aktívna oblasť | 223.68×125.82 mm |
| obrys | 238.6×148 mm |
| povrch | |
| jas | 500 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC) |
| Doba odozvy | 40 (Max.)(Tr+Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 9S3PWLEDWithout Driver |
| signálové rozhranie | LVDS (1 ch, 8-bit), 40 pins |
| vstupné napätie | 3.3/3.3V (Typ.)(VDD/AVDD) |
| aplikácie | IA |
