| Číslo dielu | PQ 3Qi-01 |
| Značka | Pixel Qi |
| Veľkosť | 10.1 |
| Aplikácia | EBK |
| Rozhodnutie | 1024×600 |
| Zloženie | LCM |
| Jas | 235 |
| CR | 100:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | Pixel Qi |
| panelový model | PQ 3Qi-01 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 10.1 inch |
| rozhodnutie | 1024(RGB)×600 , WSVGA |
| režim zobrazenia | Normally Black, TM/RF/TF |
| aktívna oblasť | 222.72×125.28 mm |
| obrys | 235×143×5.2 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 235 cd/m² (Typ.) |
| kontrastný pomer | 100 : 1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193140% |
| Doba odozvy | 6.5/13.5 (Typ.)(Tr/Td) |
| pozorovací uhol | 30/30/30/30 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (1 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | EBK |
