| Číslo dielu | G104S1-L01 |
| Značka | Innolux |
| Veľkosť | 10.4 |
| Aplikácia | IA |
| Rozhodnutie | 800×600 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 700:1 |
| Farby | 262K/16.2M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | CHIMEI INNOLUX |
| panelový model | G104S1-L01 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 10.4 inch |
| rozhodnutie | 800(RGB)×600 , SVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 211.2×158.4 mm |
| obrys | 243×184×7.3 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 700:1 (Typ.) |
| zobraziť farby | 262K/16.2M (6-bit / 6-bit + FRC), CIE193153% |
| Doba odozvy | 5.0/11.0 (Typ.)(Tr/Td) |
| pozorovací uhol | 80/80/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (1 ch, 6/8-bit), 20 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | IA |
| G104S1-L01 | Innolux | 10.4 | 800×600 |
| G104SN02 V0 | AUO | 10.4 | 800×600 |
| G104SN02 V1 | AUO | 10.4 | 800×600 |
| G104SN02 V2 | AUO | 10.4 | 800×600 |
| G104SN03 V0 | AUO | 10.4 | 800×600 |
| G104SN03 V1 | AUO | 10.4 | 800×600 |
| G104SN03 V4 | AUO | 10.4 | 800×600 |
| G104SN03 V5 | AUO | 10.4 | 800×600 |
| G104SN05 V0 | AUO | 10.4 | 800×600 |
| G104STN01.0 | AUO | 10.4 | 800×600 |
| G238HAN01.0 | AUO | 23.8 | 1920×1080 |
| KG057QV1DB-G00 | Kyocera | 5.7 | 320×240 |
| LB150X02-TL01 | LG Display | 15.0 | 1024×768 |
| LM8V31 | SHARP | 7.7 | 640×480 |
| LQ9D03B | SHARP | 8.4 | 640×480 |
| PD064VL1 | E Ink | 6.4 | 640×480 |
| PD064VT5 | E Ink | 6.4 | 640×480 |
| S088WX03 | CDTECH | 8.8 | 1280×320 |
| TX18D200VM0EAA | KOE | 7.0 | 1920×1080 |
| TX23D12VM0CAA | KOE | 9.0 | 800×480 |
