| Číslo dielu | VVX07F015M00 |
| Značka | Panasonic |
| Veľkosť | 7.0 |
| Aplikácia | PAD |
| Rozhodnutie | 1200×1920 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 1200:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | MIPI |
| značka panelu | Panasonic |
| panelový model | VVX07F015M00 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 1200(RGB)×1920 , WUXGA |
| režim zobrazenia | IPS, Normally Black, Transmissive |
| aktívna oblasť | 94.5×151.2 mm |
| obrys | 104.52×161.87×2.4 mm |
| povrch | Hard coating |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 1200:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193172% |
| Doba odozvy | 30 (Max.)(Tr+Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 4S6PWLEDWithout Driver |
| signálové rozhranie | MIPI (4 data lanes), 40 pins |
| vstupné napätie | 1.8/3.7V (Typ.)(VCC/VDD) |
| aplikácie | PAD |
