| Číslo dielu | TM070WA-22L06 |
| Značka | SANYO |
| Veľkosť | 7.0 |
| Aplikácia | CNS |
| Rozhodnutie | 480×234 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 100:1 |
| Farby | |
| Podsvietenie | CCFL |
| Rozhranie | Analog |
| značka panelu | TORISAN |
| panelový model | TM070WA-22L06 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 480(RGB)×234 |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 154.08×87.05 mm |
| obrys | 167×102 mm |
| povrch | Antiglare |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 100:1 (Min.) |
| zobraziť farby | |
| Doba odozvy | 30/20 (Typ.)(Tr/Td) |
| pozorovací uhol | 60/60/30/40 (Max.)(CR≥5)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 1 pcsCCFL |
| signálové rozhranie | TFT Specific Analog RGB, 24 pins |
| vstupné napätie | 5.3/15.0/-14V (Typ.)(VSH/VGH/VGL) |
| aplikácie | CNS |
