| Číslo dielu | TX38D14VC0CAA |
| Značka | KOE |
| Veľkosť | 15.0 |
| Aplikácia | DMPC |
| Rozhodnutie | 1024×768 |
| Zloženie | LCM |
| Jas | 200 |
| CR | 300:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | HITACHI |
| panelový model | TX38D14VC0CAA |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 15.0 inch |
| rozhodnutie | 1024(RGB)×768 , XGA |
| režim zobrazenia | IPS, Normally Black, Transmissive |
| aktívna oblasť | 304.128×228.096 mm |
| obrys | 350×265 mm |
| povrch | |
| jas | 200 cd/m² (Typ.) |
| kontrastný pomer | 300:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 25/25 (Typ.)(Tr/Td) |
| pozorovací uhol | 80/80/80/80 (Min.)(CR≥20)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (1 ch, 8-bit), 20 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
