| Číslo dielu | TM056KDH02 |
| Značka | Tianma |
| Veľkosť | 5.6 |
| Aplikácia | VDP |
| Rozhodnutie | 320×234 |
| Zloženie | LCM |
| Jas | 330 |
| CR | 300:1 |
| Farby | Full color |
| Podsvietenie | WLED |
| Rozhranie | Analog |
| značka panelu | TIANMA |
| panelový model | TM056KDH02 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 5.6 inch |
| rozhodnutie | 320(RGB)×234 |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 113.28×84.708 mm |
| obrys | 126.5×100 mm |
| povrch | Antiglare |
| jas | 330 cd/m² (Typ.) |
| kontrastný pomer | 300:1 (Typ.) |
| zobraziť farby | Full color , CIE193150% |
| Doba odozvy | 25 (Typ.)(Tr+Td) |
| pozorovací uhol | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 2S7PWLEDWithout Driver |
| signálové rozhranie | TFT Specific Analog RGB, 26 pins |
| vstupné napätie | 5/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikácie | VDP |
