| Číslo dielu | TM050LDZ00 |
| Značka | Tianma |
| Veľkosť | 5.0 |
| Aplikácia | CNS |
| Rozhodnutie | 240×400 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 200:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | TIANMA |
| panelový model | TM050LDZ00 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 5.0 inch |
| rozhodnutie | 240(RGB)×400 , WQVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 65.16×108.6 mm |
| obrys | 76.3×123.4×12.9 mm |
| povrch | Antiglare |
| jas | 400 cd/m² (Min.) |
| kontrastný pomer | 200:1 (Min.) |
| zobraziť farby | 262K (6-bit), CIE193170% |
| Doba odozvy | 40 (Max.)(Tr+Td) |
| pozorovací uhol | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 1S10PWLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 6/8-bit) + SPI, 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | CNS |
