| Číslo dielu | T-51750GD065J-FW-ADN |
| Značka | Kyocera |
| Veľkosť | 6.5 |
| Aplikácia | IA |
| Rozhodnutie | 640×480 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 300:1 |
| Farby | 262K |
| Podsvietenie | CCFL |
| Rozhranie | TTL |
| značka panelu | OPTREX |
| panelový model | T-51750GD065J-FW-ADN |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 6.5 inch |
| rozhodnutie | 640(RGB)×480 , VGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 132.48×99.36 mm |
| obrys | 158×120.36 mm |
| povrch | Antiglare (Haze 9%) |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 300:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193139% |
| Doba odozvy | 15/16 (Typ.)(Tr/Td) |
| pozorovací uhol | 55/55/30/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 6-bit), 31 pins |
| vstupné napätie | 3.3/5.0V (Typ.)(VCC) |
| aplikácie | IA |
| A065VL01 V2 | AUO | 6.5 | 800×480 |
| C065GW03 V0 | AUO | 6.5 | 400×240 |
| G065VN01 V1 | AUO | 6.5 | 640×480 |
| L5F30818P04 | SONY | 6.5 | 800×480 |
| LQ065Y5DZ01 | SHARP | 6.5 | 800×480 |
| NL6448BC20-08E | NLT | 6.5 | 640×480 |
| NL6448BC20-20 | NLT | 6.5 | 640×480 |
| NL6448BC20-35D | NLT | 6.5 | 640×480 |
| T-51750GD065J-FW-ADN | Kyocera | 6.5 | 640×480 |
| TX17D01VM2EAB | KOE | 6.5 | 640×480 |
| DLC0700YZG-T-6 | Other | 7.0 | 1024×600 |
| G057VTN01.0 | AUO | 5.7 | 640×480 |
| G104XGE-L05 | Innolux | 10.4 | 1024×768 |
| G170EG01 V1 | AUO | 17.0 | 1280×1024 |
| HSD190MEN6-A01 | HannStar | 19.0 | 1280×1024 |
| LM64P101R | SHARP | 7.2 | 640×480 |
| LQ104V1DG11 | SHARP | 10.4 | 640×480 |
| NL3224AC35-10 | NLT | 5.5 | 320×240 |
| NL6448BC26-09 | NLT | 8.4 | 640×480 |
| PM070WL3 | E Ink | 7.0 | 800×480 |
