| Číslo dielu | A065VL01 V2 |
| Značka | AUO |
| Veľkosť | 6.5 |
| Aplikácia | MP4 |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 250:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | AUO |
| panelový model | A065VL01 V2 |
| typ panelu | LTPS TFT-LCD , LCM |
| veľkosť panelu | 6.5 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 143.4×79.2 mm |
| obrys | 157.2×89.2 mm |
| povrch | Antiglare (Haze 8%) |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 250:1 (Typ.) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 12/18 (Typ.)(Tr/Td) |
| pozorovací uhol | 55/55/45/60 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 4S1PWLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 6-bit), 80 pins |
| vstupné napätie | 3.3/10.5/13.5/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikácie | MP4 |
