| Číslo dielu | PW080XU4 |
| Značka | E Ink |
| Veľkosť | 8.0 |
| Aplikácia | CNS |
| Rozhodnutie | 480×220 |
| Zloženie | LCM |
| Jas | 300 |
| CR | 400:1 |
| Farby | Full color |
| Podsvietenie | WLED |
| Rozhranie | Analog |
| značka panelu | PVI |
| panelový model | PW080XU4 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 8.0 inch |
| rozhodnutie | 480(RGB)×220 |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 180.72×94.27 mm |
| obrys | 193×108.3×7 mm |
| povrch | Antiglare |
| jas | 300 cd/m² (Typ.) |
| kontrastný pomer | 400:1 (Typ.) |
| zobraziť farby | Full color |
| Doba odozvy | 15/25 (Typ.)(Tr/Td) |
| pozorovací uhol | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 3S9PWLEDWithout Driver |
| signálové rozhranie | TFT Specific Analog RGB, 30 pins |
| vstupné napätie | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VCCG/AVDD/VGH/VEE) |
| aplikácie | CNS |
