| Číslo dielu | NL10276AC30-07 |
| Značka | NLT |
| Veľkosť | 15.0 |
| Aplikácia | DMPC |
| Rozhodnutie | 1024×768 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 300:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | TTL |
| značka panelu | NEC |
| panelový model | NL10276AC30-07 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 15.0 inch |
| rozhodnutie | 1024(RGB)×768 , XGA |
| režim zobrazenia | Normally Black, Transmissive |
| aktívna oblasť | 304.128×228.096 mm |
| obrys | 330×256×30 mm |
| povrch | Hard coating (2H) |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 300:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC), CIE193160% |
| Doba odozvy | 10/10 (Typ.)(Tr/Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 8 pcsCCFLEmbedded (Inverter) |
| signálové rozhranie | TTL (2 ch, 8-bit), 75 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
