| Číslo dielu | N133I6-L10 |
| Značka | Innolux |
| Veľkosť | 13.3 |
| Aplikácia | NBPC |
| Rozhodnutie | 1280×800 |
| Zloženie | LCM |
| Jas | 345 |
| CR | 700:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | CMO |
| panelový model | N133I6-L10 8 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 13.3 inch |
| rozhodnutie | 1280(RGB)×800 , WXGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 286.08×178.8 mm |
| obrys | 307.4×203.2×3.75 mm |
| tvarový štýl | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 345 cd/m² (Typ.) |
| kontrastný pomer | 700:1 (Typ.) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 3/7 (Typ.)(Tr/Td) |
| pozorovací uhol | 70/70/55/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhranie | LVDS (1 ch, 6-bit), 30 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | NBPC |
