| Číslo dielu | N133I7-L01 |
| Značka | Innolux |
| Veľkosť | 13.3 |
| Aplikácia | NBPC |
| Rozhodnutie | 1280×800 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 500:1 |
| Farby | 262K |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | CMO |
| panelový model | N133I7-L01 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 13.3 inch |
| rozhodnutie | 1280(RGB)×800 , WXGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 286.08×178.8 mm |
| obrys | 299×195×5.5 mm |
| tvarový štýl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| povrch | Glare (Haze 0%), Hard coating (2H), Reflection 1.0% (Max.) |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193148% |
| Doba odozvy | 3/7 (Typ.)(Tr/Td) |
| pozorovací uhol | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (1 ch, 6-bit), 20 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | NBPC |
| LP133WH2-TLM4 | LG Display | 13.3 | 1366×768 |
| LP133X3-A | LG Display | 13.3 | 1024×768 |
| LT133EE09400 | TOSHIBA | 13.3 | 1366×768 |
| N133I1-L01 | Innolux | 13.3 | 1280×800 |
| N133I5-L01 | Innolux | 13.3 | 1280×800 |
| N133I6-L01 | Innolux | 13.3 | 1280×800 |
| N133I6-L09 | Innolux | 13.3 | 1280×800 |
| N133I6-L10 | Innolux | 13.3 | 1280×800 |
| N133I7-L01 | Innolux | 13.3 | 1280×800 |
| NV133FHM-N52 | BOE | 13.3 | 1920×1080 |
| LP125WH2-TLB1 | LG Display | 12.5 | 1366×768 |
| LP140WD2-TLE2 | LG Display | 14.0 | 1600×900 |
| LP154WX7-TLP1 | LG Display | 15.4 | 1280×800 |
| LP171WX2-TLB1 | LG Display | 17.1 | 1440×900 |
| LTN141XB-L03 | Samsung | 14.1 | 1024×768 |
| LTN170BT06-G01 | Samsung | 17.0 | 1440×900 |
| N133HSE-EA3 | Innolux | 13.3 | 1920×1080 |
| N133I7-L01 | Innolux | 13.3 | 1280×800 |
| N140FGE-LA2 | Innolux | 14.0 | 1600×900 |
| N156HGE-LA1 | Innolux | 15.6 | 1920×1080 |
