| Číslo dielu | M215H3-LA1 |
| Značka | Innolux |
| Veľkosť | 21.5 |
| Aplikácia | DMPC |
| Rozhodnutie | 1920×1080 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | CMO |
| panelový model | M215H3-LA1 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 21.5 inch |
| rozhodnutie | 1920(RGB)×1080 , FHD |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 476.64×268.11 mm |
| obrys | 495.6×292.2×12.1 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 1.3/3.7 (Typ.)(Tr/Td) |
| pozorovací uhol | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 13S6PWLEDWithout Driver |
| signálové rozhranie | LVDS (2 ch, 8-bit), 30 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
| M215HGE-L21 | Innolux | 21.5 | 1920×1080 |
| M215HGE-P02 | Innolux | 21.5 | 1920×1080 |
| M215HGK-L30 | Innolux | 21.5 | 1920×1080 |
| M215HJJ-L30 Rev.C1 | Innolux | 21.5 | 1920×1080 |
| M215HTN01.1 | AUO | 21.5 | 1920×1080 |
| M215HW01 V5 | AUO | 21.5 | 1920×1080 |
| M215HW01 V6 | AUO | 21.5 | 1920×1080 |
| M215HW01 VB | AUO | 21.5 | 1920×1080 |
| M215HW03 V1 | AUO | 21.5 | 1920×1080 |
| M215HW03 V1Q0 | AUO | 21.5 | 1920×1080 |
| LM150X08-A4KD | LG Display | 15.0 | 1024×768 |
| LM190E08-TLJ7 | LG Display | 19.0 | 1280×1024 |
| LM220WE1-TLM1 | LG Display | 22.0 | 1680×1050 |
| LM270WQ3-SLA1 | LG Display | 27.0 | 2560×1440 |
| LTM150XH-L06 | Samsung | 15.0 | 1024×768 |
| LTM170EU-L11 | Samsung | 17.0 | 1280×1024 |
| M150XN07 V1 | AUO | 15.0 | 1024×768 |
| M156B1-L02 | Innolux | 15.6 | 1366×768 |
| MT190AW02 V.W | Innolux | 19.0 | 1440×900 |
| NL10276AC28-05R | NLT | 14.1 | 1024×768 |
