| Číslo dielu | LM201U05-SLA3 |
| Značka | LG Display |
| Veľkosť | 20.1 |
| Aplikácia | DMPC |
| Rozhodnutie | 1600×1200 |
| Zloženie | LCM |
| Jas | 300 |
| CR | 800:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | LG.Philips LCD |
| panelový model | LM201U05-SLA3 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 20.1 inch |
| rozhodnutie | 1600(RGB)×1200 , UXGA |
| režim zobrazenia | IPS, Normally Black, Transmissive |
| aktívna oblasť | 408×306 mm |
| obrys | 432×331.5×25.5 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193172% |
| Doba odozvy | 7/9 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 6 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (2 ch, 8-bit), 30 pins |
| vstupné napätie | 18.0V (Typ.) |
| aplikácie | DMPC |
| LM201U02-A3C3 | LG Display | 20.1 | 1600×1200 |
| LM201U04-A3 | LG Display | 20.1 | 1600×1200 |
| LM201U04-A3K6 | LG Display | 20.1 | 1600×1200 |
| LM201U04-A3KC | LG Display | 20.1 | 1600×1200 |
| LM201U04-SL03 | LG Display | 20.1 | 1600×1200 |
| LM201U05-SLA1 | LG Display | 20.1 | 1600×1200 |
| LM201U05-SLA3 | LG Display | 20.1 | 1600×1200 |
| LM201U05-SLL1 | LG Display | 20.1 | 1600×1200 |
| LQ201U1LW31 | SHARP | 20.1 | 1600×1200 |
| V201B1-L01 | Innolux | 20.1 | 1366×768 |
| CLAA185WA03 | CPT | 18.5 | 1366×768 |
| LM201WE3-TLF8 | LG Display | 20.1 | 1680×1050 |
| LM230WF3-SLQ1 | LG Display | 23.0 | 1920×1080 |
| LM240WU7-SLB3 | LG Display | 24.0 | 1920×1200 |
| LM300WQ5-SDA1 | LG Display | 30.0 | 2560×1600 |
| LTM240CS02 | Samsung | 24.0 | 1920×1200 |
| M190EN03 V2 | AUO | 19.0 | 1280×1024 |
| M201EW02 V9 | AUO | 20.1 | 1680×1050 |
| M236HJJ-L30 | Innolux | 23.6 | 1920×1080 |
| M270HGE-L10 | Innolux | 27.0 | 1920×1080 |
