| Číslo dielu | LTD121LA3SG-201 |
| Značka | TOSHIBA |
| Veľkosť | 12.1 |
| Aplikácia | NBPC |
| Rozhodnutie | 1024×768 |
| Zloženie | LCM |
| Jas | 200 |
| CR | 200:1 |
| Farby | 262K |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | Toshiba Matsushita |
| panelový model | LTD121LA3SG-201 |
| typ panelu | LTPS TFT-LCD , LCM |
| veľkosť panelu | 12.1 inch |
| rozhodnutie | 1024(RGB)×768 , XGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 245.76×184.32 mm |
| povrch | Hard coating (3H), Antireflection |
| jas | 200 cd/m² (Typ.) |
| kontrastný pomer | 200:1 (Typ.) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 50/50 (Max.)(Tr/Td) |
| pozorovací uhol | 30/30/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (1 ch, 6-bit), 20 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | NBPC |
