| Číslo dielu | LQ170K1LW02 |
| Značka | SHARP |
| Veľkosť | 17.0 |
| Aplikácia | GM |
| Rozhodnutie | 1280×768 |
| Zloženie | LCM |
| Jas | 300 |
| CR | 600:1 |
| Farby | 16.2M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | SHARP |
| panelový model | LQ170K1LW02 3 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 17.0 inch |
| rozhodnutie | 1280(RGB)×768 , WXGA |
| režim zobrazenia | P-MVA, Normally Black, Transmissive |
| aktívna oblasť | 369.6×221.76 mm |
| obrys | 413.8×259×16 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastný pomer | 600:1 (Typ.) |
| zobraziť farby | 16.2M (6-bit + FRC) |
| Doba odozvy | 20 (Typ.)(Tr+Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (1 ch, 8-bit), 20 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | GM |
