| Číslo dielu | LQ035LC111 |
| Značka | Innolux |
| Veľkosť | 3.5 |
| Aplikácia | DSC |
| Rozhodnutie | 320×240 |
| Zloženie | LCM |
| Jas | 380 |
| CR | 300:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | Serial RGB |
| značka panelu | ChiHsin |
| panelový model | LQ035LC111 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 3.5 inch |
| rozhodnutie | 320(RGB)×240 , QVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 70.08×52.56 mm |
| obrys | 76.9×63.9×3.36 mm |
| povrch | Antiglare, Antireflection |
| jas | 380 cd/m² (Typ.) |
| kontrastný pomer | 300:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193150% |
| Doba odozvy | 10/15 (Typ.)(Tr/Td) |
| pozorovací uhol | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 6S1PWLEDWithout Driver |
| signálové rozhranie | Serial RGB (8-bit) + SPI, 36 pins |
| vstupné napätie | 3.3/5.0V (Typ.)(VCC/VDD) |
| aplikácie | DSC |
