| Číslo dielu | LQ024B7UD01 |
| Značka | SHARP |
| Veľkosť | 2.4 |
| Aplikácia | MPH |
| Rozhodnutie | 160×240 |
| Zloženie | LCM |
| Jas | 28 |
| CR | 110:1 |
| Farby | 65K |
| Podsvietenie | WLED |
| Rozhranie | CPU |
| značka panelu | SHARP |
| panelový model | LQ024B7UD01 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 2.4 inch |
| rozhodnutie | 160(RGB)×240 , HQVGA |
| režim zobrazenia | TN, Normally White, Transflective |
| aktívna oblasť | 33.6×50.4 mm |
| obrys | 41.8×66.6 mm |
| povrch | Hard coating (3H) |
| jas | 28 cd/m² (Typ.) |
| kontrastný pomer | 110:1 (Typ.)(Transmissive)12:1 (Typ.)(Reflective) |
| zobraziť farby | 65K |
| Doba odozvy | 30/50 (Typ.)(Tr/Td) |
| pozorovací uhol | 50/50/60/50 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 2S1PWLEDWithout Driver |
| signálové rozhranie | CPU, 24 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | MPH |
