| Číslo dielu | LK235D3HA0S |
| Značka | SHARP |
| Veľkosť | 23.6 |
| Aplikácia | DMPC |
| Rozhodnutie | 1920×1080 |
| Zloženie | CELL |
| Jas | 0 |
| CR | 5000:1 |
| Farby | 16.7M |
| Podsvietenie | No B/L |
| Rozhranie | Mini LVDS |
| značka panelu | SHARP |
| panelový model | LK235D3HA0S |
| typ panelu | a-Si TFT-LCD , CELL |
| veľkosť panelu | 23.6 inch |
| rozhodnutie | 1920(RGB)×1080 , FHD |
| režim zobrazenia | ASV, Normally Black, Transmissive |
| aktívna oblasť | 521.28×293.22 mm |
| obrys | 532.875×303.7 mm |
| povrch | Antiglare (Haze 2%), Hard coating (3H) |
| priepustnosť | 4.5% (Typ.)(with Polarizer) |
| kontrastný pomer | 5000:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC) |
| Doba odozvy | 4 (Typ.)(G to G) |
| pozorovací uhol | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 240Hz |
| signálové rozhranie | Mini LVDS, 160 pins |
| aplikácie | DMPC |
| HR236WU1-100 | BOE | 23.6 | 1920×1080 |
| HR236WU3-301 | BOE | 23.6 | 1920×1080 |
| HT236F01-100 | BOE | 23.6 | 1920×1080 |
| LK235D3HA0S | SHARP | 23.6 | 1920×1080 |
| LQ235D1LW03 | SHARP | 23.6 | 1920×1080 |
| M236H1-L07 | Innolux | 23.6 | 1920×1080 |
| M236HJJ-L30 | Innolux | 23.6 | 1920×1080 |
| M236HJK-L5B | Innolux | 23.6 | 1920×1080 |
| P236MWF1 R2 | IVO | 23.6 | 1920×1080 |
| V236BJ1-LE1 | Innolux | 23.6 | 1366×768 |
| HT215F01-100 | BOE | 21.5 | 1920×1080 |
| LM215WF3-SDC2 | LG Display | 21.5 | 1920×1080 |
| LTM200KT03 | Samsung | 20.0 | 1600×900 |
| LTM220MT05 | Samsung | 22.0 | 1680×1050 |
| M170E5-L0A | Innolux | 17.0 | 1280×1024 |
| M185XTN01.2 | AUO | 18.5 | 1366×768 |
| M215HTN01.1 | AUO | 21.5 | 1920×1080 |
| M220Z1-L05 | Innolux | 22.0 | 1680×1050 |
| MT215DW01 V.1 | Innolux | 21.5 | 1920×1080 |
| NL10276AC28-05R | NLT | 14.1 | 1024×768 |
