| Číslo dielu | G156XW01 V3 |
| Značka | AUO |
| Veľkosť | 15.6 |
| Aplikácia | IA |
| Rozhodnutie | 1366×768 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 500:1 |
| Farby | 16.2M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | AUO |
| panelový model | G156XW01 V3 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 15.6 inch |
| rozhodnutie | 1366(RGB)×768 , WXGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 344.232×193.536 mm |
| obrys | 363.8×215.9×9.8 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.) |
| zobraziť farby | 16.2M (6-bit + FRC), CIE193167% |
| Doba odozvy | 6/2 (Typ.)(Tr/Td) |
| pozorovací uhol | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (1 ch, 8-bit), 30 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | IA |
| B156XW03 V1 | AUO | 15.6 | 1366×768 |
| G156XW01 V0 | AUO | 15.6 | 1366×768 |
| G156XW01 V1 | AUO | 15.6 | 1366×768 |
| G156XW01 V3 | AUO | 15.6 | 1366×768 |
| LP156WD1-TLB1 | LG Display | 15.6 | 1600×900 |
| LP156WH1-TLC2 | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLAA | LG Display | 15.6 | 1366×768 |
| LTN156AT17-D01 | Samsung | 15.6 | 1366×768 |
| LTN156AT20-P02 | Samsung | 15.6 | 1366×768 |
| LTN156AT35-H01 | Samsung | 15.6 | 1366×768 |
| G101STN01.0 | AUO | 10.1 | 1024×600 |
| G185XW01 V1 | AUO | 18.5 | 1366×768 |
| KCG089HV1AA-G00 | Kyocera | 8.9 | 640×240 |
| LB104S01-TL02 | LG Display | 10.4 | 800×600 |
| LMG9980ZWCC-01 | KOE | 12.1 | 800×600 |
| LQ056A5GG01 | SHARP | 5.6 | 320×234 |
| LQ104V1DG5A | SHARP | 10.4 | 640×480 |
| LQ84S02 01A | SHARP | 8.4 | 800×600 |
| NL6448BC18-01F | NLT | 5.7 | 640×480 |
| TCG121SVLQAPNN-AN20 | Kyocera | 12.1 | 800×600 |
